Precision Mold Scanning with i-Scan Light

Project Overview

Our client needed precise 3D scanning of two mold components to assist with inspection and CAD modeling. Accuracy was critical, as the data would directly influence their manufacturing and quality control processes.

Our Solution

We utilized our in-house scanning technology, the i-Scan Light API, to capture detailed 3D data of both mold parts. The scanning process focused on preserving intricate surface features, edges, and complex geometries—ensuring the data could be used for high-precision inspection and reverse engineering.

Deliverables

Results & Client Impact

Scan Visuals

Full Scan Output of Mold Part 📸 “High-precision 3D scan generated using i-Scan Light”
Surface Detail Close-Up 📸 “Zoomed-in view highlighting intricate mold features”
Optional Color Mapping or Overlay 📸 “Deviation map visual for dimensional inspection (if available)”
Reduced cost of rework due to early deviation detection

“Voxel 3D Tech’s scan quality helped us detect minute design deviations. Their quick turnaround and precision gave us full confidence moving forward with mold manufacturing.”

— Client Feedback
